MYIR | System-On-Modules (SOMs)

MYC-LT527

The MYC-LT527 System-On-Module (SoM) is a compact, high-performance embedded module powered by the Allwinner T527 processor. Featuring an Octa-core ARM Cortex-A55 CPU and a G57 MC1 GPU, it offers up to 2 TOPs of NPU performance, ensuring excellent multimedia and AI capabilities. With onboard memory configurations of 2GB/4GB LPDDR4, 16GB/32GB eMMC, and various peripheral expansions, it is ideal for industrial, AIoT, and multimedia applications. It runs on Linux, Android, and Ubuntu OS..

  • Detail
  • Special Features
  • Specification

The MYC-LT527 integrates the powerful Allwinner T527 processor, combining an Octa-core ARM Cortex-A55 with a 600MHz HiFi4 DSP and a 2 TOPs NPU. It features extensive peripheral support, including a 381-pin expansion interface for various I/O options like MIPI-CSI, HDMI, and LVDS, along with robust network connectivity through Gigabit Ethernet, USB 3.0, and more. With 2GB/4GB LPDDR4 memory and 16GB/32GB eMMC storage, it provides ample resources for high-performance computing. The SoM is perfect for embedded systems requiring multimedia, AI, and robust connectivity.

  • Processor: Allwinner T527 with Octa-core ARM Cortex-A55, up to 1.8GHz.

  • NPU: 2 TOPs Neural Processing Unit for enhanced AI performance.

  • Memory & Storage: 2GB/4GB LPDDR4, 16GB/32GB eMMC storage, 32Kbit EEPROM.

  • Graphics: ARM G57 MC1 GPU supporting high-performance video processing.

  • Connectivity: 381-pin LGA expansion interface with extensive I/O capabilities.

  • Video Decoding: Supports 4K@30fps H.265, H.264, VP9 decoding.

  • Expansion: 2x MIPI-CSI, HDMI, eDP, MIPI-DSI, LVDS outputs for versatile display options.

  • Operating Systems: Supports Linux 5.15, Android 13, and Ubuntu 22.04.

  • Processor: Allwinner T527, Octa-core ARM Cortex-A55, up to 1.8GHz, 2 TOPs NPU

  • Memory: 2GB/4GB LPDDR4

  • Storage: 16GB/32GB eMMC, 32Kbit EEPROM

  • Graphics: ARM G57 MC1 GPU

  • I/O: 381-pin LGA, MIPI-CSI, HDMI, eDP, LVDS, USB, CAN, Ethernet

  • Power: 5V/3A

  • Temperature: -40~85°C (Industrial Grade)

  • OS: Linux 5.15, Android 13, Ubuntu 22.04
